Optical fibres

SIB Labs Colour Research Laboratory

väritutkimuslaboratorio

Colour research instruments

Spot Measurement Devices

Spektrometri_laite.

Fiber NIR Spectrometer, Avantes

NIR spectrometry in 1000–2500 nm wavelength range, with the help of a two-meter optical fiber.

Spektometri_laite.

UV-VIS-NIR spectrometry in the 200–1150 nm wavelength range, with the help of a 2-3 m optical fiber.

Spektrometri_Hamamatsu:

Spectrometry in the 200–950 nm wavelength range, with the help of a 3 m optical fiber.

Spektrometri.

Reflection, transmission, and absorption measurements. Wavelength range: 200-2500 nm (up to 175-3300 nm).

Fluorescence spectrophotometer PerkinElmer FL-8500

Fluorescence Spectrophotometer, PerkinElmer FL-8500 is made for excitation-emission material characterization. Wavelength range for excitation and emission is 200-900 nm. Wavelength Scan Speed is 60,000 nm/min. Smallest wavelength step 1 nm, and wavelength accuracy 0.5 nm. Wavelength reproducibility is 0.2 nm.

Spektrikamerat

Spectral Video camera.

Camera has 7-channels: 2x blue, 2x green, 2x red and 1x IR cannel (700-100 nm). Frame rate: 30 frames/sec. Output video data can be converted to individual frames for processing.



Nuance LCTF kamera.

Spectral measurement in the 420–720 nm wavelength range, spectral images are created by scanning in the direction of the wavelength.



Nuance_LCTF kamera.

Spectral measurement in the 450–950 nm wavelength range, spectral images are created by scanning in the direction of the wavelength.



Hyperspektri

Line Scanning Spectral Imaging System includes scanner 1x1.5 m and two cameras: visible V10 (400-1000 nm) and SWIR N25 (1000-2500 nm).



Visible Spectral camera.

Visible spectral camera Specim V10 in Specim Line Spectral Imaging System. Spatial pixels 2144, spectral pixels (spectral bands) 1080, wavelength range 400-1000 nm.



SWIR spectral camera

SWIR spectral camera Specim N25 in Specim Line Spectral Imaging System. Spatial pixels 320, spectral pixels (spectral bands) 250, wavelength range 1000-2500 nm.



Specim IQSpectral Camera.

Line scanning spectral camera. Line scanner built into optics, no physical scanner is needed. VNIR 400-1000 nm (CMOS), spatial pixels 512, spectral bands 204, ENVI format, object distance 150 – ∞ mm, FOV 31 x 31 degrees, weight 1.3 kg.



Other cameras and devices

Monochromator Kratos.

Mechanically operated monochromator.

Monochromator_Newport.

Oriel Conerstone 130, CS130-USB-1-MC, operated by a computer.

CCD camera Retiga 4000DC.

The Retiga 4000DC CCD camera was design especially for low-light, high-dynamic-range applications and supports light fluorescence and polarization applications.

Gigahertz Optik Integating Sphere 500mm

Integrating Sphere with diameter of 500 mm.

Flir SC 7600 thermal.
  • Spectral range 1500–5000 nm
  • Detector with cooling
  • Active pixels 640 x 512
  • Temperature calibration -20 – +300 °C
  • Thermal resolution 0.03 °C
  • Frame rate 25, 50 or 100 Hz
  • Filter wheel for 4 filters
Nikon MA-200 käänteismikroskooppi.

Microscope has 2 camera ports, suitable for spectral imaging in combination with an LCTF spectral camera, for example.

Konica_Värimittari_Spektrometri.

Konica-Minolta CL-500A

  • The CL-500A is a lightweight, compact illuminance spectrophotomete.
  • The CL-500A can measure illuminance, color temperature, CRI (Color Rendering Index), chromaticity, and spectral power distribution.
Photometrics monochrome camera for medical imaging

CMOS sensor 2048x2048 pixels (4.2 Mp) with 1.3 e- read noise.

Pixel size 6.5 x 6.5 microns (sensor size 13.3 x 13.3 mm).
Operating Wavelength specified for the camera 200 nm to 1000 nm (QE 20% at 1000, QE approx. 5% at 1100, peak QE of > 95% @550 nm).

Frame rate: 2048x2048 @ 16 bit : 43.5 fps with USB;  2048x2048 @ 11 bit : 63 fps with speed card.

IR_kamera.

Flir SC 7600

  • Spectral range 1500–5000 nm
  • Detector with cooling
  • Active pixels 640 x 512
  • Temperature calibration -20 – +300 °C
  • Thermal resolution 0.03 °C
  • Frame rate 25, 50 or 100 Hz
  • Filter wheel for 4 filters
Flir SC 2200 IR kamera.

Flir SC 2200

  • Spectral range 1000-2500 nm
  • Filters
